Chapter 5: Day-to-Day Maintenance

5 – 2

Notes To reload cards into the kiosk or desktop encoder

For the

kiosk

station

1 Open the cabinet door using the keys provided with your

system.

For the

desktop

station

2 Unlock and slide the cover off of the encoder enclosure.

See Figure 5.2.

3 Remove the card weight. See Figure 5.3.

4 Load up to 300 cards into the kiosk hopper or 150 cards

into the desktop hopper. See Figure 5.3.

Figure 5.1 ID Express Station™ Kiosk showing the card

hopper

Card slot

Card hopper

Figure 5.2 Desktop enclosure showing the card hopper

Card hopper

Encoder

cover
